Akubela HyPanel Plus PS52V2-D1-US
Smart Home Control Panel, 4'' Touchscreen, Wi-Fi 6, Bluetooth 5.4, ZigBee 3.0 Gateway, 1-Gang Dimmer.
Akubela PS52V2-D1-US HyPanel Plus is a versatile smart control panel built for stylish and intelligent home living. Running Android 12, it features a 4-inch multi-touch screen and 2 touch buttons, with a built-in 1-gang dimmer for direct control of dimmable lighting. This all-in-one solution integrates a ZigBee 3.0 gateway, smart intercom, and full home automation capabilities. With built-in sensors, WiFi 6, Bluetooth 5.4, and metal housing, it fits flush in US-standard wall boxes, delivering both elegance and high performance.
Key Features:
- Excellent performance with Android 12 system
- 4” multi-touch screen with energy saving mode
- 2 touch buttons, suitable for the whole family
- 1-gang dimmer, can be directly connected to dimming lights
- Smart intercom, ZigBee gateway, home automation – all in one
- Multiple built-in sensors for intelligent automation
Product Specifications:
- Model: PS52V2-D1-US
- Power Supply: 100 ~ 260VAC, 50/60Hz
- Output: 400W total; 400W/220V/gang (resistive); 200W/110V/gang (resistive); 150W/gang (LED/CFL)
- Operation System: Android 12
- RAM/ROM: 2GB / 8GB
- Screen Size: 4” multi-touch screen
- Screen Resolution: 480×480 pixels
- Screen Brightness: 210 cd/㎡
- Wi-Fi: WiFi 6, IEEE 802.11a/b/g/n/ac/ax
- Bluetooth: Bluetooth 5.4
- Ethernet Port: 1×RJ45, 10/100Mbps adaptive
- ZigBee: ZigBee 3.0
- Microphone: Dual microphones, -26dBFS
- Speaker: Single speaker, 8Ω / 1.5W
- Material: Metal
- Button: 2 touch buttons
- Environment: For indoor use only
- Proximity Sensor: 30 ~ 60cm
- Light Sensor: Low-level lux detection
- Temperature Sensor: ±1℃, Range: -10℃ ~ 55℃
- Humidity Sensor: ±5%, Range: 10% ~ 90%RH (non-condensing)
