Akuvox X933W

Akuvox X933w

Indoor Monitor – Android Smart intercom

Akuvox X933W Indoor Monitor is a smart intercom with an Android 9 operating system and a luxury Italian design; suitable for apartments, complexes, home automation systems and villas.  With built-in dual speakers and dual microphones, it allows two-way audio communication with other units in the network. All in-home automation devices can be easily managed and controlled by it. The 7-inch capacitive touch screen X933W offers energy-saving mode. Besides that, it also offers offline voice assistant feature.

Akuvox X933W - Key Features:
  • 7″ capacitive touch screen with energy saving mode
  • HD audio and video communication
  • Dual speakers
  • Built-in offline voice assistant
  • Voice pickup distance up to 5 meters
  • Voice recognition accuracy upto 95%
  • Privacy protection with native voice data
  • Echo Cancellation
  • Voice Activation Detection
  • Comfort Noise Generator
  • Automatic Gain Control
Akuvox X933W – Product Specification:
  • Manufacturer: Akuvox
  • Model: X933W
  • Resolution: 1280 x 800
  • Dimension:5mm
  • Front panel: Plastic
  • WiFi: Built-in
  • Bluetooth: BLE 4.1
  • Operating System: Android 9
  • Tamper Resistant: Support
  • Display Mode: Normally black, Transmissive
  • Installation: Wall-mounted
Akuvox X933W Technical Specifications:

At a Glance

  • Android 9 OS
  • 7-inch capacitive touch
  • screen with energy saving mode
  • Reception of a HD picture from the door communicator
  • Two-way audio communication with other units in the network
  • Complies with SIP standard for easy integration in every SIP capable PBXes
  • Powered by PoE or external source
  • Support US or European electrical wall box mounting
  • Built-in smart voice assistant

Physical & Power

  • Front panel: Plastic
  • Display: 7 Inch IPS LCD
  • Screen: 7 Inch capacitive touch screen
  • RAM / ROM: 2GB / 8GB
  • Wi-Fi: IEEE802.11 b/g/n, @2.4GHz 
  • Bluetooth: BLE 4.1
  • RS485 port: Support
  • Bell in: 1
  • Relays Out: 2
  • Microphone: Dual
  • Microphone, -26 dB
  • Speaker: Dual speakers, 4Ω/ 3W
  • I/O: 8
  • Tamper Resistant: Support
  • Ethernet ports: 1 x RJ45, 10/100Mbps adaptive
  • 802.3af Power-over-Ethernet
  • 12V DC connector (if not using PoE)
  • Installation: Wall-mounted
  • Wall-mounted Dimension: 205x148x27.5mm
  • Working Humidity: 10~90%
  • Working Temperature: -10°C ~ +45°C
  • Storage Temperature: -20°C ~ +70°C

Touch Screen Display

  • Display Mode: Normally black,Transmissive
  • LCD Size: 7 inch (Diagonal)
  • Aspect Ratio: 16:10
  • Resolution: 1280 x 800
  • Contrast ratio: 900:1
  • Luminance: 350 cd/m2
  • Viewing Angle: 89° Left, 89° Right, 89° Upper, 89° Lower
  • Touch Screen: Projected capacitive

Audio

  • SIP v1 (RFC2543), SIP v2 (RFC3261)
  • Narrowband audio codec: G.711a, G.711μ, G.729
  • DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info
  • Echo Cancellation
  • Voice Activation Detection
  • Comfort Noise Generator
  • Automatic Gain Control

Video

  • Streaming formats: H.263 & H.264

Networking

  • Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Deployment & Maintenance

  • Auto-Provisioning
  • Web management portal
  • Web-based packet dump
  • Configuration backup / restore
  • Firmware upgrade
  • System logs (include door access logs)

Voice assistant

  • Voice pickup distance up to 5 meters
  • Voice recognition accuracy up to 95%
  • Privacy protection with native voice data
  • Support English

Application Scenario

  • Modern interiors
  • Apartment complexes
  • Home automation systems
  • Villas
